UNIBODY ALL-WELDED CORRIDOR LOCKERS
Our third generation Marquis Booksafe locker includes reinforced double frame, unibody construction and a modern seamless deep-drawn stainless steel recessed handle. The industry's first and best single-point, all-welded corridor locker just got better, stronger and more durable, and backed by our written lifetime warranty. Doors are provided without louvers for a clean flush front.
Standard:
18 gauge continuous piano hinge
Standard:
Our rugged 11 gauge single-point latch is MIG welded to Hollow-T frame
Standard:
Deep-drawn 304 stainless steel recessed handle multi-point gravity-lift type latching and Antimicrobial Recessed Handle Finger Lift Cover
Standard:
3" wide 18 gauge full height door stiffener
Features:
Body/Frame:
All-welded unibody construction,
16 gauge solid sides integral with frame, 16 gauge continuous top, 18 gauge solid back, 16 gauge bottom
16 gauge solid sides integral with frame, 16 gauge continuous top, 18 gauge solid back, 16 gauge bottom
Doors:
14 gauge plain doors with a 3" wide 18 gauge full
height door stiffener are standard. Louvered, Security-Plus
and diamond perforated door styles are
height door stiffener are standard. Louvered, Security-Plus
and diamond perforated door styles are
Handle:
Deep-drawn 304 seamless stainless steel recessed
handle with single-point latching
handle with single-point latching
Latching:
Single-point maintenance-free quiet latching
with 11 gauge MIG welded latch
with 11 gauge MIG welded latch
Hooks:
2-single hooks and 1-double hook is standard.
• 1- double hook only for triple tier 1-double
• 1-double & 1- single hook for 9" wide openings 30” and higher
• 1- double hook only for triple tier 1-double
• 1-double & 1- single hook for 9" wide openings 30” and higher
Shelves:
16 gauge Hat shelf
Standard:
18 gauge continuous piano hinge
Standard:
Our rugged 11 gauge single-point latch is MIG welded to Hollow-T frame
Standard:
Deep-drawn 304 stainless steel recessed handle multi-point gravity-lift type latching and Antimicrobial Recessed Handle Finger Lift Cover
Standard:
3" wide 18 gauge full height door stiffener
Optional Slope Top:
Slope tops are an attractive way prevent items and debris from collecting on top of locker bays.
Download Documents:
| Simple Specifications | 3-Part CSI Specifications |
|---|---|
Simple Specifications:
3-Part CSI Specifications:
